XTREME 15 MIL VAPOR BARRIER 14 FT. X 210 FT.

Description

Tex-Trude Xtreme Vapor Barrier/Retarder is a high performance film designed for use under concrete slabs to stop moisture migration and to control radon gas, methane, and other soil gases or contaminants. Xtreme Vapor Barriers/ Retarders are extruded in a single sheet of material composed of the latest generation of virgin polyolefin resins. This high puncture resistant Vapor Barrier/Retarder, has superior performance to other materials in the industry and is available in 15 mil.

Key Features

• ASTM E 1745, Class A,B,C – standard specification for water vapor retarders used in contact with soil or granular fill under concrete slabs
• Water Vapor Permeance: 0.0078
• Puncture Resistance: 4000
• Tensile Strength: 64
• Methane Transmission Rate: 252.55
• Life Expectancy: Indefinite
• Roll Dimensions: 14 x 140 1960 ft2
• Roll Weight: 142 lb
• Installation:
  • Under Concrete Slab: Install Xtreme Vapor Barrier/Retarder over tamped earth, sand or aggregate base. Follow ASTM 1643 guidelines. Unroll and completely cover the area to receive the building slab or other specified areas. The seams must overlap a minimum of six inches and be sealed with Xtreme Seam Tape, Xtreme Thin Tape, or Xtreme Grip Back Tape. All exposed penetrations also must be sealed. A physical inspection of the area should be performed prior to installation. Note: Only use Xtreme Tapes, Xtreme Mastic, and Xtreme SLM to seal seams, edges, and penetrations.
• Limited Warranty:
  • Tex-Trude warrants this product to meet the published specifications and to be free of defects in workmanship and materials at the time of shipment from our factory. If any Xtreme material proves to contain manufacture defects that substantially affect the performance, then Tex-Trude will at their option replace the material or refund the purchase price. This limited warranty is the only warranty offered by Tex-Trude, LP as it relates to Xtreme products. There are no other warranties, including the implied warranties of merchantability or fitness for a particular purpose. Tex-Trude specifically disclaims liability for any incidental, consequential, or other damages.
